Pro Horizontal Laminar Air Flow Cabinet

Features:

• Designed so as to meet the requirements of US Federal Standard 209 B (BS 5295) providing particle free air to meet class 100 conditions.


• Cabinet is fabricated of wooden board laminated with sunmica OR CRC Sheet (powder coated) OR stainless steel (SS-304grade) (as ordered).


• Working table is made of Stainless Steel Sheet (SS-304 grade).


• Front doors are made out of thick transparent plexiglass.


• Heavy Duty Motor operates with a minimum noise level.


• Working area is illuminated by fluorescent lighting fitted to the unit.


• Supplied complete with S.S. Satin finish Table Top, Transparent front door, Static Pressure Manometer, Built-in U.V. Germicidal light and Cock for gas, air or vacuum line, HEPA filters and pre-filter.


• Air drawn through pre-filter is made to pass through highly effective HEPA (High-Efficiency Particular Air) filters. The prefilter fitted extends the life of the HEPA filter drastically. Fitted with HEPA Filter made from water-resistant, fire retardant, imported microfine glass fiber media; conforms to EU – 14 Grade, with an efficiency rating better than 99.999% for 0.3 μ. These filters are designed to accommodate higher air flow volume.


• Prefilter is made from Non-Woven Synthetic with HDPE mesh and Al expanded mesh on air leaving side; conforms to EU – 4 / G-4 Grade, with the efficiency of down to 10 microns. These filters can be cleaned by compressed air & also washable.


• Mounted on heavy tubular stand with lockable castors.


• With Solid Side Walls and transparent front door.


• To work on 220/230 volts A.C. supply.

Technical Specifications And Ordering Information

• Main filter: HEPA Filter made from water-resistant, fire retardant, imported microfine glass fiber media; conforms to EU - 14 Grade, with an efficiency rating better than 99.999% for 0.3 μ. These filters are designed to accommodate higher air flow volume.


• Prefilter: Prefilter is made from Non-Woven Synthetic with HDPE mesh and Al expanded mesh on air leaving side; conforms to EU – 4 / G-4 Grade, with the efficiency of down to 10 microns. These filters can be cleaned by compressed air & also washable.


• Control: Microprocessor controlled with LCD display with air velocity sensor and digital display of air velocity across the worktable.


• Illumination: Fluorescent Lamp 40W


• Sterilizing: UV Germicidal Tube.


• Front door: Made of Plexi Glass


• Utility: Gas/Air cock


• Supply Voltage & Frequency: AC 230V, 50/60 Hz


• MOC (CABINET): Wooden or CRC Sheet (powder coated) or Stainless Steel (SS-304)


• Work Table: Stainless Steel (SS-304 grade)

Options:

• Magnehelic Gauge (To track filter pressure) in lieu of static pressure manometer.


• Electronic Filter choke alarm. (Differential pressure monitor)


• Spare U.V. Germicidal Tube (1.5 feet).


• Spare U.V. Germicidal Tube (3.0 feet).
