Low Temperature Deluxe Model BOD Incubator

Low Temperature Deluxe Model BOD Incubator

MOQ : 1 Piece

Business Type Exporter, Supplier
Country of Origin India
Type Forced Convection Type
Brand Name MAC
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Model
MSW-121
Compressor
Hermetically Sealed Air Cooling Compressor System
Temperature Range
5°C to 60°C (Resolution 0.1°C)
Accuracy
± 0.5°C (at 37°C)
MOC Outer
CRC Sheet duly powder coated
MOC Inner
Chamber and trays made of Stainless Steel (SS-304)
Safety
Over Temperature Limiter Switch Prevents Overheating
Electric Supply
220/230V AC, 50/60Hz

Description:

  • Most suitable for experiments requiring low-temperature conditions like microorganism or activation, cell culture process of animals and plants, good storage and desalting process of enzyme extracts, etc.
  • With a solid double-walled door and a full view inner plexiglass door enables inspection and monitoring of inner chamber specimens without distributing the process temperature.
  • Excellent quality magnetic gum packing door gasket for an external door.
  • User-oriented design of shelves makes you adjust each space of shelves without difficulty.
  • Forced air circulation at the triple-walled back by the durable coaxial blower, maintains optimum temperature uniformity and homogeneity.
  • High-grade HIGH PRESSURE FOAMED IN-PLACE PUF INSULATION between outer and inner chamber for minimal thermal losses.
  • Caster wheel mounted for easy portability.
  • Front double walled door is provided with lock and key arrangement.
  • Door operated illumination lamp is fitted inside the chamber for easy visibility.
  • Finned tube evaporator facilitates uniform and faster cooling effects.
  • Temperature Controller: Microprocessor Based Digital Temperature Indicator-Cum-Controller with LED OR LCD Display OR TFT Touch Screen Display Controller (Option)



Options:

  • Interior illumination arrangement with a cyclic timer to control cyclic illumination conditions.
  • Humidity generation and control arrangement through a Digital Humidity Indicator-Cum-Controller from 55% RH to 95% RH at cool temperatures.
  • G-LOG – Fully automatic digital (FAD) with real time data logger with CENTRONIC PRINTER PORT (DOT MATRIX) and USB Port for taking data (Paperless Data Recording) and Saving ON PC. (DOT Matrix Printer to customer scope)
  • P-LOG – Fully automatic digital (FAD) with real time data logger with CENTRONIC PRINTER PORT (DOT MATRIX) and RS-485 PC communication port with 21 CFR compliant software and data cable for logging data directly to your PC. (DOT Matrix Printer and PC to customer scope)
  • Automatic Voltage Stabilizer to cost extra.

Yes! I am interested


Microprocessor Digital Controller with LED Display

Model Display Type Chamber Size (WxDxH) (in mm) Chamber Capacity Chamber Volume No of shelves
#LTI-4(LED) LED 455x415x610 112 ltrs. 4.0 Cuft 2
#LTI-6(LED) LED 505x415x830 171 ltrs. 6.1 Cuft 2
#LTI-10(LED) LED 580x565x900 285 ltrs. 10.0 Cuft 3
#LTI-12(LED) LED 660x580x900 340 ltrs. 12.0 Cuft 3
#LTI-16(LED) LED 660x660x970 450 ltrs. 16.0 Cuft 4
#LTI-20(LED) LED 660x660x1250 560 ltrs. 20.0 Cuft 4
#LTI-28(LED) LED 800x800x1250 800 ltrs. 28.0 Cuft 6
#LTI-35(LED) LED 800x800x1580 1000 ltrs. 35.0 Cuft 6

Microprocessor Digital Controller with LCD Display

Model Display Type Chamber Size (WxDxH) (in mm) Chamber Capacity Chamber Volume No of shelves
#LTI-4(LCD) LCD 455x415x610 112 ltrs. 4.0 Cuft 2
#LTI-6(LCD) LCD 505x415x830 171 ltrs. 6.1 Cuft 2
#LTI-10(LCD) LCD 580x565x900 285 ltrs. 10.0 Cuft 3
#LTI-12(LCD) LCD 660x580x900 340 ltrs. 12.0 Cuft 3
#LTI-16(LCD) LCD 660x660x970 450 ltrs. 16.0 Cuft 4
#LTI-20(LCD) LCD 660x660x1250 560 ltrs. 20.0 Cuft 4
#LTI-28(LCD) LCD 800x800x1250 800 ltrs. 28.0 Cuft 6
#LTI-35(LCD) LCD 800x800x1580 1000 ltrs. 35.0 Cuft 6

TFT Touch Screen Display Controller

Model Display Type Chamber Size (WxDxH) (in mm) Chamber Capacity Chamber Volume No of shelves
#LTI-4(TFT) TFT 455x415x610 112 ltrs. 4.0 Cuft 2
#LTI-6(TFT) TFT 505x415x830 171 ltrs. 6.1 Cuft 2
#LTI-10(TFT) TFT 580x565x900 285 ltrs. 10.0 Cuft 3
#LTI-12(TFT) TFT 660x580x900 340 ltrs. 12.0 Cuft 3
#LTI-16(TFT) TFT 660x660x970 450 ltrs. 16.0 Cuft 4
#LTI-20(TFT) TFT 660x660x1250 560 ltrs. 20.0 Cuft 4
#LTI-28(TFT) TFT 800x800x1250 800 ltrs. 28.0 Cuft 6
#LTI-35(TFT) TFT 800x800x1580 1000 ltrs. 35.0 Cuft 6
